24V Flow Light Strip (WIC) – Stunning Lighting Effects

SKU: YF-CWIC12MM420-24V

Original price was: $500.00.Current price is: $230.00.

Per Box

Enhance your space with YIFORD’s 24V Flow Light Strip (WIC)—a high-density, individually addressable LED strip featuring COB design for dotless chasing effects. Perfect for architectural lighting, signage, and creative installations. IP68 waterproof, programmable, and ultra-flexible.

  • Prices are per box.
  • Prices will appear after all available options have been selected.
  • Shipping cost will appear after filling in the recipient’s company address and zip code.
Description

Product Overview

The YIFORD 24V Flow Light Strip (WIC) is a premium individually addressable LED strip designed for seamless, smooth color transitions and dynamic lighting effects. With 420 LEDs/m and 10 ICs/m, this COB-based digital LED strip ensures dotless illumination, making it ideal for high-end decorative and functional lighting applications.

Part Number: YF-CWIC12MM420-24V
Width: 12mm
Thickness: 2mm
LED Density: 420 LEDs/m (10 ICs/m)
Cutting Length: 100mm
Power Consumption: Up to 13W/m
Voltage: 24V
LED Type: COB (Chip-on-Board)
Waterproof Rating: IP68

Part Number: YF-CWIC12MM420-24V

Specifications:

Weight 6 kg
LED Color

WIC

Voltage

24VDC

LED Quantity

420 LEDS Per Meter

PCB Width

12mm

Power

13W/M

Cuttable Length

100mm

IC Quantity

10PCS/Meter

Length Per pcs

5 Meter

Box

100 Meters

bright, vivid, and dynamic lighting effects

Key Features

features

● Pure white digital LED strip, dotless chasing color with COB design.
● 256-level gray chip is used to achieve more delicate change effects, consistent brightness and mixing effects.
● 10 pixels per meter, cutting distance 100mm.
● Double layer FPC, balancing the voltage dropping, heat dissipation and flexibility.

✅ Dotless COB design ✅ 420 LEDs/m ✅ Individually addressable ✅ IP68 waterproof ✅ Programmable effects ✅ 24V stable power

Pixel-Level Programmability

  • 420 LEDs per meter ensure smooth, continuous illumination without visible dots.
  • COB (Chip-on-Board) technology eliminates hotspots, delivering pure white and vibrant colors.

Individually Addressable LEDs

  • Each LED can be independently controlled for dynamic animations, chasing effects, and custom patterns.
  • Works with Arduino, Raspberry Pi, and popular LED controllers (e.g., WLED, FastLED).

IP68 Waterproof Protection

  • Fully encapsulated in silicone for dustproof and waterproof performance.
  • Ideal for outdoor signage, pool lighting, and wet environments.

Low Voltage & High Efficiency

  • 24V operation reduces voltage drop over long runs, ensuring consistent brightness.
  • Up to 13W/m power consumption—energy-efficient yet powerful.

Flexible & Easy to Install

  • Ultra-thin (2mm) and bendable—fits curved surfaces and tight spaces.
  • Cut every 100mm for precise customization.

Programmable & Versatile Applications

  • Compatible with  SPI controllers for professional lighting setups.
  • Supports smooth color fading, strobe, and gradient effects.
  •

How to Use and Installation instructions

  1. Connect to a compatible controller (e.g., SP108E, WLED, or Arduino).
  2. Power with a 24V DC supply (ensure sufficient amperage for long strips).
  3. Program effects using software like FastLED, WLED, or proprietary apps.
  4. Install with adhesive backing or mounting clips—suitable for both indoor and outdoor use.
  • Clean the surface: Ensure the surface is free of dust and grease for better adhesion.
  • Cut the strip: Most LED strips have marked cutting points for safe and precise trimming.
  • Adhesive backing: Press firmly after sticking to ensure the strip stays in place.
  • Connect to the controller: Match the positive and negative terminals correctly to avoid damage.

Product Applications

✔ Architectural Lighting (facades, coves, staircases)
✔ Retail & Commercial Displays (signage, shelves, bars)
✔ Automotive & Marine Lighting (underglow, interior accents)
✔ Event & Stage Lighting (dynamic backdrops, DJ setups)
✔ Home Decoration (TV backlighting, under-cabinet lighting)
✔ Outdoor Landscaping (pathways, garden accents)

Why Choose YIFORD

🔹 Premium COB Technology – Smoother light than standard LED strips.
🔹 Rigorous Quality Control – Tested for durability and performance.
🔹 Custom Solutions Available – Tailored lengths and controllers.
🔹 Global Shipping & Support – Fast delivery and expert assistance.

Upgrade Your Lighting with YIFORD’s 24V Flow Light Strip (WIC)!
📞 Contact us today for bulk orders and custom lighting solutions.
