SP801E WiFi Art-Net LED Controller

1.AP(Access Point) mode: Controller and Phone connect directly, controller works as an access point. 1> Go to your phone Settings page, connect the controller(SSID like SP801E_XXX, the default password is 12345678);
2> Open the BanlanX App ,Click “+” button to configure the new SP801E controller，then the controller will be showed on the device list;

2.STA(Station) mode: Controller and phone are in one same WiFi network, in this network, users can operate the controller. There are two ways to configure the controller into the local WiFi network: 1> Connect your phone or tablet to a 2.4G Wi-Fi network.(Doesn’t support 5.0G Wi-Fi network)
2> Open the App and click“+” button to scan devices, click Add manually and select SP801E controller in the device category;
3> Input your Wi-Fi network password;
4> BluFi config and AP config: •BluFi config: Press and hold device’s “STA/AP” button until the green led indicator flashes,then the device enters the network configurationstate, clicknext and selcet the device you want to add; •AP config:Switching the device to the AP mode, click next and connect your phone’s WIFI to the named like SP801E_XXXhotspot, passwordis12345678,and return to the APP;
5> Pressing next step to wait for the configure processing finish;
6>After the configuration finished, the LED indicator will turn into solid green, the controller will be showed on the device list.
